GLASSLINE – 30

GLASSLINE-30 is a full glass wall system made with aluminum profiles for glasses between 8 - 11,14mm.

Maximum wall height:

3500 mm

Soundproofing:

Rw = 36 dB*

* 55.2 laminated with more soundproof glass

Suitable glasses with a thickness:

8 – 11,14 mm

Technical Description

CBC5C2C1-92A5-4B07-AEC0-67D6B9485190

The width of the profile is 20mm and the height is 30mm.

The standard surface finish of aluminum profiles is natural (silver) anodizing but it is also possible to order a painted surface according to the RAL colour catalogue.

Possible types of glass are tempered, laminated or tempered-laminated.
The surface of the glass can be bright, very bright, mass-tinted, background-painted or matte.

Adjacent glass panes are joined together with silicone tape. If desired, the joint can be covered with a 30mmx2mm aluminum Decor profile.
Decor profile can be glued anywhere on the glass surface to create exiting looks.

The standard floor profile height is 30mm, but it is also possible to choose a 70mm profile with the same width.

A 5mm black circular cross-section EPDM top seal is used as the glass seal.

The structures adjacent to the product must be strong enough to allow profiles to be attached to them.

Soundproofing measured in laboratory (Rw):

  • Rw = 33dB (with 10mm glass and aluminum threshold)
  • Rw = 36dB (with 55.2 laminated with more soundproof glass)

Documentation

CBC5C2C1-92A5-4B07-AEC0-67D6B9485190

Compatible products

PORTA - 92A

PORTA - 53G

PORTA - 53GF

PORTA - 53GS

PORTA - 53W

PORTA - 53WF

PORTA - 53WS

PORTA - 92X

ELZONE - 92A

ELZONE - 92X

WALLEND - R

ALUSLIDE - 12

FGSLIDE - 30

WOODSLIDE - 30

WOODSLIDE - 41
